Мини-плата порта COM Mini PCIE USB на RS422 RS485 RS232 с разъемом DB9 для модема PDA GPS штрих-кода цифрового преобразователя ISDN терминального адаптера.

Мини-плата порта COM Mini PCIE USB на RS422 RS485 RS232 с разъемом DB9 для модема PDA GPS штрих-кода цифрового преобразователя ISDN терминального адаптера.

Features

USB 2.0 High Speed (480 Mbits/sec.) and Full Speed (12 Mbits/sec.) compatible
Standards: conforming to USB1.0, 1.1 and 2.0
USB 2.0 Compliant, Full-Speed  (12 Mbps)
Full size Mini PCIe  module type combo
MiniPCIe via USB & USB pin header
RS232 Data Rates: 300bps to 1 Mbps
RS422/RS485 Data Rates: 300bps to 10 Mbps
FIFO Buffer: 4K byte transfer, 4K byte receiver
UART interface support for 7 or 8 data bits,1 or 2 stop bits and even/odd/mark/space/none,Flow control none,hardware and xon/xoff
1.Isolation voltage: 2500V,High common-mode transient immunity: >25 kV/μs
2.500W surge protection and±23KV ESD protection

3.Signal indication: indicator lights for Power (PWR), Send (TXD) and Receive (RXD)
4.Operating Temperature:-40 to +85

The model is ready the USB signal on both MiniPCIe side (Pin 36, 38, 2, 4) and Pin Header (J2). While using, please kindly select only one of the two.
System Requirements:
Windows XP,Vista,7,8,10 32,64-bit;
Windows Server 2K3,2K8,2K12 32,64-bit
Windows XP Embedded
Windows CE 4.2, 5.0 and 6.0
Mac OS-X
Linux 3.2 and greater
Android
Applications
POS Printer Terminal
Networking System
Industrial and Power Meter
