KINGJOIN high quality automatic parking electronic barrier system parking lot system automatic boom barrier for highway toll collection

When you order, it is recommended that you leave the direction of the barrier gate on the desired retention device. Left fixed or Right fixed. Boom length 1 to 5Meter custom, thank you

Automatic Parking Barrier

1. aluminuim cabimet 2. full automatic 3. Manual release device to operate the barrier when power failure 4. Barrier motor with die-casting aluminum alloy is high-hermetic and easy for heat dissipation 5. Motor cooling fan to avoid the over-heating possibility 6. Automatic reversing when the barrier boom meets the obstruction 7. Auto closing realization through menu setting on the control panel 8. The barrier works well with infrared photocells, loop detectors, card readers, ticket dispensers, manual switch (wire control), and traffic light 9. RS485 Communication Module is compatible 10. compatible with IP and parking system

Functions & Features

1. Open the barrier gate by motor wheel when power off and automatic locking when power on 2. Balanced boom running with a motor transmission of cranks and shafts 3. Remote control to operate the barrier gate 4. Auto-reverse when the boom meets obstruction 5. Infrared photocells interface is available 6. Loop detector interface is available 7. Well-integrated with car parking system equipments, with wire control (push button) 8. Interface for traffic light 9. Offering dry contact signal for car parking system (COM, NC, NO) 10. Auto-delay when closing (adjustable) 11. Remote control frequency: 418MHz, 433MHz 12. Boom with protective rubber band(Optional)

Technical Data

1. Working temperature:-40~+75 degree centigrade. 2.Power: 220V±10%, 110V±10%, 50/60HZ 3.Rated power: 80W 4.Relative humidity: ≤90% 5.Remote control distance: ≥30m 6.Net weight: 50kgs 7.Speed: 3S, 6S 8.Protection Class: IP54

FAQ:

Q: Why to choose High Speed Barrier Gate? 1. High Speed Barrier Gate adopts special machine core, swing away boom holder and boom. This barrier gate runs in high speed but stably. The running time is 1 second. It can be used for highway toll. 2. High Speed Barrier Gate uses swing away boom holder. The boom is out of the holder when it is hit, which protects the barrier core and prolong lifetime of the barrier. 3. High Speed Barrier Gate uses the first generation motor. It is stable and has long service life performance, running 3 million times. Its housing is made of galvanized steel with 1.5mm thickness, and painted, so that the barrier can be used in door and outdoor. 4. The barrier core is special and main parts are aluminum alloy casting. The barrier gate will automatically reverse when the boom meets the obstruction. The barrier works well with infrared photocells, loop detectors, the boom will automatically rise up when it meets pedestrian and vehicles. Manual release device can operate the barrier when power failure. Q: Why the barrier boom would open automatically? A: Please check if the limit switch is on the right position; if not, please adjust the Limit Switch. Please refer to last page of Barrier Gate Manual. Or you can adjust the adjusting screw. And the last step is to check the intensity of the spring. Q: What's the remote control distance? A: In general, most of 418 remote control can cover 100 meters, but it is not safe and stable to control the barrier gate from 100 meters away. we recommends using the remote control within 30 meters or 50 meters.

Optional accessories：

loop detector: ttps:/item/4000775821222.html

UHF RFID: https:/item/33034250123.html?spm=2114.12010612.8148356.4.621010benyF3kd
