Hdmi сплиттер 1X4 Поддержка Hdcp 2 0 Hdmi2.0 разветвитель 4K для Apple Tv Ps4 | Электроника

Compliant with HDMI 2.0, and HDCP 2.2 standards. Backward compliant with HDMI1.4,HDCP1.X. Support RGB and YCbCr 444/422/420 format. Support CSC (color space conversion) matrix and 420/422/444 conversion(1:1;1:2;2:1). Support 4:1 Down-scaling for 4Kx2K content to 1080P display on legacy display. Bypass, CSC-processed, down-scaled content can be selected on each of the 2 output ports individually.
Serial data rate at up to 6.0Gbps, capable of supporting HDMI 2D video up to 4Kx2K@60Hz and 3D up to 4Kx2K@30Hz. Support PackedPixel mode up to 1080P@60Hz. Support Deep Color Mode at up to 36 bits (12 bits/color). Support HDMI 2.0 and HDMI 1.4 3D format with frame packing/Top and Bottom/side by side mode. Integrated pre-programmed HDCP keys. Pure hardware HDCP 2.2 and 1.x engine increasing the robustness and security of HDCP operation.
Embedded EDID RAM saves external EDID ROM costs. Active source and sink detection for auto low power state implementation. Embedded CEC/RCP hardware. Disconnectable input terminations with auto-calibrated impedances. Adaptive input equalization supporting long and short cables at the same time. Programmable TMDS output current level.
Programmable source terminations compliant with HDMI 2.0 standard,providing optimal source data eyes at high speeds.
Plug Type:US Plug,it applies to Canada, India, Japan, Mexico, Thailand, the United States, the Philippines and so on.
Plug Type:EU Plug,it applies to Indonesia, Germany, France, Spain, Italy and so on.
Plug Type:UK plug,it applies to Malaysia, the United Kingdom and so on.
Plug Type:AU Plug,it applies to Australia and so on.
Color: silver gray
Material: aluminum alloy
HDMI version...........HDMI 2.0, HDCP 2.2
HDMI resolution..24/50/60fps/480i/480p/576i/576p/720p/1080i/1080p/2160p
Supports video color format ............24bit/deep color 30bit, 36bit, 48bit
Supports audio format...........................DTS-HD/Dolby-trueHD/LPCM7.1/
DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth........600MHz
Max baud rate.............18.0Gbps
Input/Output DDC signal .......................5Volts p-p (TTL)
1080P Input cable distance....................≤15m AWG24 HDMI standard cable
1080P Output cable distance..................≤20m AWG24 HDMI standard cable
4KX2K Input cable distance......................≤5m AWG24 HDMI standard cable
4KX2K Output cable distance..................≤10m AWG24 HDMI standard cable
Max working current....1000mA
Operating Temperature range....... (-15 to +55℃)
Operating Humidity range..........5 to 90%RH (No Condensation)
Dimension (L x W x H)..................................110x60x20(mm)
Weight...95g
Package Contents
1* dispenser
1* instruction manual
1* charger
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
