Operating  Note:

1, Temperature  Setting

Under the condition that the machine is powered on, Press the "SET" button,  At this time the temperature control  digital display in the flashing state, Through the upper and lower buttons to adjust, set the required temperature, set the finished, then press the "SET" button,  so that the  instrument to the normal temperature display state.

2.Power Supply: 400W, 220V

Usage: for phone motherboard CPU remover, like iPhone X

“SET”: it controls the temperature adjustment;

 “UP”: it rises the temperature of machine;

 “DOWN”: it reduces the temperature of machine.

3.How to use it:

1, adjust the temperature to 200 degree, and assemble the motherboard on the machine;

2, remove the cover on motherboard by tweezers, and remove the glue on edge of motherboard by special knife;

3, use a hot air gun to blow on the motherboard, and a knife to remove slightly by the other hand;

4, use a soldering iron or blade to remove the glue on motherboard after you remover the CPU (Please take care when you remove the glue).

4. Repair and Maintenance

a.   Heating plate heating plane, should be kept clean, so as not to heat the heat conduction is not uniform.

b.   Use a cleaning agent to spray the heating plane, and use soft cloth to gently wipe the residue.

c.   Finally use a soft cloth to dip a little alcohol to wipe the plane to make it clean and bright.

d.   Avoid using a sharp tool, metal tools or abrasive paper to remove the residue from the heating plane.

e.   If the machine is not used for a long time, please turn off the power, or set the temperature below 50 degrees to extend the product life.

5, Warning

a.   Separator placed on the table, the table to be flat, the material must Heat resistant.

b.   During the course of work, the heating plane is very hot around, be careful to operate, beware of burns.

c.   Heated items should pay attention to safety, high temperature will damage the heating components.

d.   Prohibit the use of the heating equipment near combustible and flammable objects.

e.   This machine is a high temperature electric product, if not use it, please cut off the power, so as to avoid accidents.
