New N-Switch Mini handle

   INFORMATIONS

ZXD1289STEENFC switches at the scene

1. Mode and Connection Description
The Switch mode:
Press Y + HOME for 2 seconds to enter Bluetooth search mode. Le D1 - LED 4 blinks and the channel indicator corresponding to successful connection is always on ( switch host assignment );
Synchronizing, or pairing with the host: LED1-LED4 running horse blinking;
Note: When the handle is in synchronization mode, it will hibernate automatically if it is not synchronized within 2.5 minutes.
Android mode:
Press A + HOME for 2 seconds to enter Bluetooth search mode. LED is LED 2 and LED 3. When paired, the LED will flash and the connection will be successful.


2. links mode
Press the HOME button to wake up the handle for 1 second, and it will automatically connect to the matching host after waking up. If the 10 seconds connection is unsuccessful, it will sleep automatically. Other keys have no wake-up function.


3. The charging indicator
When the handle is turned off, LED1-LED4 flashes slowly while charging, full of LED.
Low battery voltage alarm: the current indicator lights flashing (flash);
When paired, reconnect or charge low, match and repeat LED instruction priority.


4. Automatic hibernation
The main screen is closed and the handle is automatically dormant. Bluetooth mode, press the HOME key 5 seconds, disconnect from the host.
Automatically hibernate if no key is pressed within 5 minutes(including sensor immobility).


5. Low Voltage Alarm
The lithium battery voltage is less than 3.55 V ± 0.1 V, and the current channel light flash indicates the low voltage; Lithium battery voltage below 3.45 V ± 0.1 V automatically dormant.


6. Turbine and automatic city functions
1, in any mode
Press (the first time) A/B/X/Y/L1/L2/R1/R2 and Turbo keys to set the Turbo function (automatically sent when the key is pressed);
Press TURBO again(the second time) to implement the Auto Turbo function(automatically repeatedly when releasing keys);
Press A/B/X / Y/L / L2/R1 / R2 and Turbo keys alone again(for the third time) to clear the Turbo function of a single key;
Also hold down "-'' and cross key(DOWN) to clear all key Turbo functions.

2. Turbo Speed Adjustment ( with 3rd gear speed adjustable and 2nd gear by default )

Adjust mode: press 5S TURBO key and add one more file to maximum speed by hitting right 3D up.
If you press the 5S TURBO key long enough, do not put the right 3D down to the maximum speed to reduce the first gear.
Three speeds is: the continuous running under 5 per second (1);
Note: Turbo function has no memory and no LED indication. Screen capture keys in PC and Android mode are not functional.


7. The USB function
Operation mode: insert SWITCH host automatically identify SWITCH, insert PC as standard XINPPUT mode;
USB LED light indicator: SWITCH: distributed by the host; XINPUT: LED 1, LED 4 bright.
PC - USB upgrade: turned off by pressing L3 insert PC into a state - USB upgrade again, open the upgrade software according to the steps to upgrade the handle.


8. technical parameters
Turn off current 15uA below.
Matching current 30 ~ 60 ma,
Working current closed (NFC) 20 ~ 30 ma, 80 ~ 90 ma NFC open;
Charging current 150~200mA.

Packing list:1 handles, 1 charging lines.
