 100 MHz–2500 MHz 45 dB RF Detector/Controller AD8314
    　   Description: Features:

The AD8314 is a complete low-cost subsystem for the mea-surement and control of RF signals in the frequency range0.1 GHz–2.5 GHz, with a typical dynamic range of 45 dB,intended for use in a wide variety of cellular handsets and otherwireless devices. It provides a wider dynamic range and betteraccuracy than possible using discrete diode detectors. In particular,its temperature stability is excellent over the full operating range of–30°C to +85°C.

The AD8314 is available in a micro_SOIC package and con-sumes 4.5 mA from a 2.7 V to 5.5 V supply. When powereddown, the typical sleep current is 20 µA

FEATURES

Complete RF Detector/Controller Function

Typical Range –58 dBV to –13 dBV

–45 dBm to 0 dBm re 50

Frequency Response from 100 MHz to 2.5 GHz

Temperature-Stable Linear-in-dB Response

Accurate to 2.5 GHz

Rapid Response: 70 ns to a 10 dB Step

Low Power: 12 mW at 2.7 V

Power-Down to 20 μA



APPLICATIONS

Cellular Handsets (TDMA, CDMA, GSM)

RSSI and TSSI for Wireless Terminal Devices

Transmitter Power Measurement and Control

Package Contents
100% Brand New
1 X 100 MHz–2500 MHz 45 dB RF Detector/Controller AD8314
