Notice:

Please make sure the input voltage, output voltage and current in item specs when placing orders. Or we\'ll arrange the one as the item specs says.

Model

D-30A

D-30B

CH1

CH2

CH1

CH2

DC Voltage

5V

12V

5V

24V

Voltage Tolerance

2%

+3%,-7%

2%

+3%,-5%

Rated Current

4A

1A

2.2A

1A

Current Range

0.5-4A

0.1-1A

0.5-4A

0.1-1A

Rated Power

32W

32W

35W

35W

Ripple & Noise

50 mVp-p

100 mVp-p

50mVp-p

100mVp-p

DC Adjustment Range

CH1: -5%,+10%

Setup,Rise,Hold Time

200ms,50ms,30ms at full load

INPUT

Voltage Range 85~132 VAC/170~264VAC47~63 Hz,selected by switch 240~370VDC

AC Current 0.8A/115 V0.45A/ 230 V

Efficiency 72%(SKD-30A); 74%(SKD-30B)

Inrush Current Cold start 18A/115V36A/230V

Leakage Current <1mA/240VAC

PROTECTION

Over Load 105%~150%

Protection type: Shut down o/p voltage, recovers automatically after fault condition is removed

ENVIRONMENT

Working Temp., Humidity -10C~+60C;20%~90 %RH

Storage Temp., Humidity -20C~+85C,10%~95 %RH

Vibration 10~500Hz,2G 10min./1cycle,period for 60min, each along X, Y, Z axes

SAFETY

Withstand Voltage I/P-O/P: 1.5KVACI/P-FG: 1.5KVACO/P-FG: 0.5KVAC

Isolation Resistance I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD

Safety Standard Design refer to UL1012

EMC Standard Design refer to FCC Part15 J Conduction Class A

OTHERS

Weight 0.41Kg

Packing 30pcs/13.4Kg/0.86CUFT

NOTE:

1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25C of ambient temperature.

2.Ripple & noise are measured at 20MHz of bandwidth by using a 12twisted pair-wire terminated with a 0.1 &47

parallel capacitor.

3.Tolerance: includes set up tolerance, line regulation and load regulation

Product Size:

MingWei switching power supply factory is a set design, development, production in one of the high-tech professional manufacturers, the region is the first company to introduce Taiwan manufacturer of switch power supply technology, building in May 2001.

Notes on choosing a switching power supply?

To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.

What about production process of switching power supply?

Maker Industrial and Trading Company started to run businiess since 2006, which is located in Wenzhou Yueqing - The world-famous city for low-voltage electric apparatus.We owns followed subsidiary corporations:

Yueqing Maker electric Co., Ltd. concentrates on Import and Export.

Yueqing MINGWEI Switching power supply FactoryMore than 20 years of production experience,focus on production and research and development of switch power supply.
