Notice:

Please make sure the input voltage, output voltage and current in item specs when placing orders. Or we\'ll arrange the one as the item specs says.

Model SCN-800-12 SCN-800-13.5 SCN-800-15 SCN-800-24 SCN-800-27 SCN-800-48

DC output voltage 12V 13.5V 15V 24V 27V 48V

Output voltage tolerance 1% 1% 1% 1% 1% 1%

Rated output current 66A 59A 53A 33A 30A 16A

Output current range 0-66A 0-59A 0-53A 0-33A 0-30A 0-16A

Ripple and noise 150mVp-p 150mVp-p 150mVp-p 240mVp-p 240mVp-p 480mVp-p

Inlet stability 0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

Load stability 5% 5% 0.5% 0.5% 0.5% 0.5%

DC output power 800W 800W 800W 800W 800W 800W

Efficiency 80% 81% 81% 85.5% 86.5% 87%

DC voltage

adjustable range 10% 10% 10% 10% 10% 10%

INPUT

Input voltage range 85-132VAC/170-264vac/47~63Hz;230V-240V

Input current 8A/230V

Surge Current 75A/230VAC

Leakage Current <3.5mA/240VAC

PROTECTION

Overload protection 105%~150% type:FOLDBACK cut off output reset:Automatic recovery

over-voltage protection 110%-135%

High temperature protection 70C

ENVIRONMENT

temperature coefficient 0.03%C(0~50C)

Start-up,rise,hold up time 1.5s,50ms,20ms

shock resistance 10~500Hz,2G 10min./1circle,Period for 60min.,Each axes

SAFETY

Withstand voltage Input and Output internal:3KvAC,input and enclosure:1.5KvAC,output and enclosure:

0.5KvAC

Insulation Resistance Input and Output internal: input and enclosure,output and enclosure:500VDC/100M Ohms

work Temperature/humidity -10C~+60C(Refer to output derating curve),20%~90%RH

storage temperature /humidity -20C~+85C,10%~95%RH

STANDARD

Safety standards UL1950,TUV EN60950

OTHERS

Outline dimension 291*132*68mm

Weight 2.3Kgs

NOTE:

1 The above parameters test conditions are: 230VAC input, rated load, 25 C 70% RH. Humidity.

2 Tolerance: includes set up tolerance, line stability, load stability (Note 5).

3 The ripple test: 20MHz with A12 "twisted pair, interrupted with 0.1uF & 47uF capacitor short-circuit.

4 Into the line voltage stability test: full load into the line of the minimum voltage to maximum voltage.

5 Load stability test: the load from 0% to 100%, and other output at 60% rated load.

6 The output of up to maximum current, but the overall load can not exceed the maximum output power.

7 C2, 3,11 must be dismantled.

Product Size:

· We Ship to Worldwide, except APO/FPO.

· Items are shipped from China using Airmail, reach most of the countries within 10 to 20 business days.

· Delivery time depends on destination and other factors, it may takes up to 20 business days

· Noted: Fedex Maybe charge handling charges at your country, we are not responsible for this charges.

Payment:

Payment method on Aliexpress Check here help.aliexpress.com/payment_method.html

Warranty and Guarantee:

· 12 months Warranty. Buy with confidence!

· If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact me before you return it.

· If item is defective in 3 months, We will send you a replacement without extra charges, or offer refund after we receive the defective item.

· If item is defective after 3 months, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee

Other Policies:

· We are not responsible for any custom duty or import tax.

· We will leave POSITIVE FEEDBACK after receiving the payment. Please contact us if you are not satisfied with the item after receive it.

· All emails will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your email and we will reply to you as soon as possible.

MingWei switching power supply factory is a set design, development, production in one of the high-tech professional manufacturers, the region is the first company to introduce Taiwan manufacturer of switch power supply technology, building in May 2001.

Notes on choosing a switching power supply?

To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.
