AHD CCTV Camera 720P 960P 1080P Security 1MP 1.3MP 2MP CMOS AHD-M -H Outdoor IR Night Vision Analog Surveillance | Безопасность и

AHD CCTV Camera 720P 960P 1080P Security 1MP 1.3MP 2MP CMOS AHD-M -H Outdoor IR Night Vision Analog Surveillance | Безопасность и

(Please make sure your DVR support AHD camera before purchase.Thanks.)

1/4" = 1.0 Megapixels = 720P

1/3'' = 1.3 Megapixels = 960P

1/2.8'' = 2.0 Megapixels = 1080P

Key Features:

Best choice for project reconstruction.

You can upgrade an old analog security system to 1.0MP/1.3MP/2.0MP HD cameras without changing cable routes.

AHD (Analog High Definition), a new video format for enhanced CVBS (COMET*) & HD video transmission.

HD AHD camera is an over-coaxial-cable analog HD video transmission standard,

allowing long-distance HD transmission at a lower cost to meet the requirements for a complex and large installation.

Usually use Coaxial-Cable,SYV-75-3 cable can transfer video over 500meters.

Specifications

1)720P AHD Camera(Must work with AHD DVR which support AHD-M mode)

Camera

Model Number

AQL880

1/4'' 1.0MP CMOS sensor

Resolution

720P (1280*720)

Lens

3.6mm standard(2.8/6/8mm optional)

IR Distance

Power Supply

DC12V (Not included)

Working temperature

-20degree~ + 60degree

Working Humidity

10% ~ 95%

Video

Frame Rate

25fps@720P

Video Standard

HD AHD Standard ( AHD-M)

Video Output

BNC High Definition Analog

Color & B/W Switch

IR-CUT Single, Double Filter Changer

Min. Lux

0.01LUX/F1.2(Color), 0LUX (IR LED on)

Power consumption

2W(daytime),6W(night)

Transmission

Max. Transfer Distance

500 meters via 75+5 Coaxial Cable

Interface

BNC & DC Power

2)960P AHD Camera (Must work with AHD DVR which support AHD-M mode)

Model No.

AQL881

Pickup Device

1/3" Low Illumination CMOS sensor

Pixels

1280(H)*960(V)

Min. illumination

0.01Lux/F=1.2(0Lux IR ON)

White Balance

Auto

S/N Ratio

>50dB (AGC Off )

Electronic Shutter

AUTO/ 4/25-1/45,000sec

Day & Night

ICR switch

Lens

3.6MM Standard (6mm/8mm for choice)

Sync. System

Internal Sync

Video Frame Rate

1280*960@25fps

Video Output

Compliant AHD Standard

HDCVI distance

Up to 500 meters lossless transmission with 75-3 coax

Infrared LED

36 pcs LED

IR Distance

5-20m

Power Supply

DC12V(Not included)

Power Consumption

70mA/270mA(IR ON)

Working temperature

-20°C ~ 60°C

Weight

0.3kg

3)1080P AHD Camera(Must work with AHD DVR which support AHD-H mode)

Camera

Model Number

AQL882

1/2.8'' 2.0MP CMOS sensor

Resolution

1080P (1920*1080)

Lens

3.6mm standard(6mm/8mm optional)

IR Distance

Power Supply

DC12V (Not included)

Working temperature

-20degree~ + 60degree

Working Humidity

10% ~ 95%

Video

Frame Rate

25fps@1080P

Video Standard

HD AHD Standard ( AHD-H)

Video Output

BNC High Definition Analog

Color & B/W Switch

IR-CUT Single, Double Filter Changer

Min. Lux

0.01LUX/F1.2(Color), 0LUX (IR LED on)

Power consumption

2W(daytime),6W(night)

Transmission

Max. Transfer Distance

500 meters via 75+5 Coaxial Cable

Interface

BNC & DC Power

1*AHD Camera

Note:

1).Power supply is not included !!

2).3.6mm lens default ,if you need other lens(2.8mm/6mm/8mm) ,please leave a message in the order .

3). Must work with AHD DVR   .

Note: Camera doesn't include power adapter. DC 12V 1A or 2A power adapter suitable for this camera. Please click the below link to buy it separately.Thank you!
